Fixed charging stations for homes, residential buildings and businesses. Permanent infrastructure that adds value to your property and removes the dependence on a wall outlet.
With 7 kW of power, it delivers fast AC charging for residential and light commercial use. Compatible with electric vehicles of different sizes, it allows current adjustment in four levels, with manual or automatic selection for greater convenience and efficiency.
With a built-in emergency button, IP65 protection and systems against overvoltage, undervoltage, overcurrent, overheating and current leakage, the Eco Station offers greater safety for both the vehicle and the installation. Automatic shutdown in abnormal situations reinforces protection, while proper grounding ensures safe operation. Installation by a qualified electrician is recommended.
Portuguese-language panel with status and operating alerts, indicator lights for real-time monitoring and a universal Type 2 connector, compatible with most electric vehicles on the market.
Immediate shutdown in critical situations, with an easy-to-reach button.
The 7kW Wallbox was designed to deliver fast, stable and safe charging.
The EVW-70K01 adds the OCPP 1.6 protocol for integration with apps and charging networks.
4 current levels, automatic or manual, adapting the charge to your installation.
Resistant to dust and water jets, for indoor and outdoor use.
Specialized support and international certifications: FCC, ETL, CE/TÜVMARK.
7kW
LCD 4.3″
32A – automatic or manual adjustment in 4 levels (32A / 16A / 8A / 4A)
230V
50/60 Hz
Connectivity with Anatel certification (02259-25-04295)
•Wi-Fi
•Bluetooth
•OCPP protocol version 1.6
5 meters
•IP65 – Protection against dust and water jets
•FCC, ETL, CE / TÜVMARK, CQC COMPATIBLE
•Charging station
•Wall bracket
•Screws and wall plugs for wall mounting
•Warranty certificate
•Instruction manual
Dimensions and Weight
•Product: 368×256.5x130mm (without cable) | 4Kg
•Package: 509x415x279 cm | 5.2Kg
7898070355013
Input voltage > 120%, the product shuts down
Input voltage < 80%, the product shuts down
Output current > 110%, relay disconnected, the power supply must be cut off and restored
When the main board temperature reaches 85 ℃, power is reduced to 50%, and it shuts down above 90 ℃
If the ground wire or the load ground wire is broken, the relay is disconnected
AC leakage 30 mA + DC 6 mA, the product shuts down
-25oC ~ +45oC (-13oC ~ +113oC)
-35oC ~ +80oC (-31oC ~ +176oC)
5% ~ 95% RH
< 2000m
100.000H
EN 62752: 2016+A1: 2020, EN 61543: 1995/A2: 2006
